RZ Series

Cables/Plugs
  1. Cable
  2. Plugs
Single / Multi
  1. Pseudo Multi-Turn (16-bit)
  2. Multi-Turn (16-bit)
  3. Single-Turn
Bits
  1. 17bit
  2. 21bit
  3. 23bit
Diameter of Hole
  1. 6mm
  2. 8mm
  3. 9mm
Outer Diameter
  1. 44mm
  2. 48mm
收藏
  • Product description
  • Download

Uses

This product is mainly used for servo-driven control system.Provide feedback information and auxiliary signals required by accurate position and speed control unitsfor the system.



Features

  • Working temperature -20 ℃ ~+105 C

  • Current consumption < 100mA

  • Battery voltage 3.6V DC

  • Battery fault voltage 2.5V

  • Battery warning voltage 3.1V

  • Differential output

  • Single 5v Supply

  • Rise/Fall time around 100ns

  • Insulated resistance 50MQ


1741229897286793.pngRaySilicon_RZ Series Revision A0_EN.pdf
