MS1600

Outlet
  1. plug-in horizontal
Encoder Height
  1. Low
Singleturn
  1. 17 bit
Form
  1. Split
Shaft Diameter
  1. 6mm
  2. 8mm
  3. without magnet
Mounting Hole
  1. 40mm
Multiturn
  1. No Multiturn
  2. 16 bit
Serial number
  1. Magnetization
收藏
  • Product description
  • Download

Technical Parameters

  • Resolution(singleturn)：0～131071（17bits)

  • Numberoflaps(multiplelaps)：65535（16bits)

  • Accessibility：Fault warning Battery voltage warning

  • Connector：RS485

  • Communications Frequency：≤16K

  • Baud：2.5MHz

  • SupplyVoltage(Vo)：4.75V≤Vo≤5.25V

  • Differential OutputLevel(HighLevel)：1.7Vmax.

  • Differential OutputLevel(Lowlevel)：3.5Vmin.

  • Alongchangetime：＜100ns




1741227851314897.pngRaySilicon_MS Series Revision A0_EN.pdf
